Aurora LED Emerency Bulb with 6 Hour Backup B22 7W 810lm CTC

Aurora LightingSKU: AU-EM6GLSB227/30
filler
Delivered in 2 to 7 business days

Price:
Sale priceR 175.00
Stock:
In stock
Livecopper Sales person smiling at the camera

Description

The Aurora LED Emergency bulb allows the lights to stay on in the event of an unexpected power cut or load shedding.

How does the lamp know the difference between a light switch activation and a power cut?

  • The internal emergency management IC will detect the voltage of L and N
  • When the voltage of a single line is cut off (light switch activation), there is still neutral voltage so the lamp will not go into emergency mode.

What is the effect of the lamp switching if there is no other load on that switched circuit>

  • The emergency lamp will activate in emergency mode only when the IC cannot detect any voltage in the input cable (power outage), and when a loop is present in the external circuitry (The loop is created by other components on the same electrical circuit within the installation.)
  • In this scenario the resistance between L and N is very small and the IC can detect this

What conditions make the lamp work during a power outage?

  • When the IC cannot detect any voltage from the input cable (power outage)
  • When a loop is present in the external circuitry (This loop is created by other components on the same electrical circuit within the installation). In this scenario the resistance between L and N is very small and the IC can detect this
Product Features
  • Provides automatic background illumination during a power outage
  • 6 hour power storage built into existing A60 lamp profile
  • High 810lm during normal operation
  • First hour lumens = 150lm during emergency operation
  • 2-6 hours lumens >_ 100lm during emergency operation
  • 1.5KV surge protection protects against power surges from within the electrical circuit, including surges from the electricity provider

Technical Specifications
Colour: White
Material: Plastic
Lens Colour: White opal
Lens Material: Plastic
Lamp Base: B22
Lamp Technology: LED, CTC
Lamp Type: LED
Lamp Shape: A19
Lamp Style: Standard
Colour Temperature: 3000K during standard usage / 6000K during power outage
Colour Spectrum: Warm White during standard usage / Cool White during power outage
Wattage: 7W
Lumen Output: 180lm during standard usage / 150lm during power outage
Lumen per watt: -
Colour Rendering Index: 80 Ra
Beam Angle: 150°
Dimmable: No
Lamp Life Hours: 25000hrs
Battery: Lithium 3.7V 1000mA
Battery life: 6hrs
Charge time: 8hrs
Voltage: 240V
Height: 125mm
Diameter: 60mm
