![Schneider Electric Hybrid Solar Inverter System 850]()
Roll over image to zoom in
Click on image to zoom
Delivery!
Description
Product Features
- Protection - Short-circuit, Overload, High Temperature, Internal Fault, Deep Discharge, Battery Low.
- Solar Panel - Supports up to 800Wp, 12V Solar Panel Array, Voc Required between 17V to 21V.
- Battery - 12V Operating Voltage: 100Ah to 200Ah. Supports tubular, Flat plate, GEL / VRLA battery.
- Display Indications:
- Mains available
- Battery Charging through Mains or Solar Panel
- Input Voltage regulation Mode
- Power Savings
- Load Output through Battery
- Low Battery Indication
- Overload Indication
- Buzzer Sound Indications:
- Battery ON
- Low Battery Pre-Alarm
- Battery Low Shut Down
- Overload Shutdown Indication
- Short Circuit & ECO / UPS Mode Selection
Technical Specifications
| Colour: | Green and White |
| Material: | Metal and Plastic |
| Wave Type: | Pure Sine Wave |
| Operating Temperature: | 0 to 45° C |
| Relative Humidity: | 95% RH Non Condensing |
| Rated Capacity: | 850VA |
| Output: |
DC Output: 12V DC, 20A / AC Output: 230V, 50Hz |
| Amperage: | 40Amp / 12V |
| Voltage Window (Eco Mode) | 100V - 290V |
| Voltage Window (UPS Mode) | 180V - 260V |
| Height: | 135mm |
| Width: | 315mm |
| Length: | 375mm |
| Weight: | 11.5kg |
