![CBi Mini Rail Surge Protector QKL-3(13) 3P 275V with Indication - 40kA]()
Roll over image to zoom in
Click on image to zoom
Delivery!
Description
Product Features
- LED indication of the SPD's condition - while ON, the SPD is functional, if OFF and the mains power is still available, then the SPD is no longer functional and should be replaces
- Thermal disconnect device (prevents potential thermal runaway problems)
- One port SPD (no series impedance)
- Requires to be backed up by a QF MCB
Safety Features
- Requires to be backed up by a QF MCB
- Surge Protection Devices should be installed by a trained professional to prevent any damages caused by incorrect installation
- Class II Surge Protection Devices are only to be used where items are not subjected to direct lightning strikes and the voltage / current surges are reduced in magnitude
Technical Specifications
| Colour: | Black |
| Material: | Copper and polycarbonate |
| Mounting Type: | Mini Rail |
| Escutcheon: | 57mm |
| Poles: | 3 |
| Short Circuit Withstand: | 5kA |
| Nominal Discharge Current (Inom): | 20kA |
| Maximum Discharge Current (Imax): | 40kA |
| Voltage: | 275Vac |
| Width: | 39mm |
| Length: | 84.8mm |
| Depth: | 66mm |
| Class of Surge Protection Device: | II |
| IP Rating: | IP20 |
| Weight: | 426g |
| Technical Document: | Download |
