Gewiss DIN Mini Circuit Breakers 1P 63A C 10kA 1M


Gewiss DIN Mini Circuit Breakers 1P 63A C 10kA 1M
Regular price
R 129.00
Sale price
R 129.00
Regular price
Unit price
per
R90.00 delivery in 2 to 7 business days

When will I get my order?

×
Estimated Delivery Times

Main Centers

Johannesburg

Durban

Pietermaritzburg

Cape Town

Port Elizabeth

Bloemfontien

East London

George

Nelspruit

Polokwane

Newcastle

Richards Bay

1 - 3 Business Days
Regional Areas 2 - 5 Business Days
Outlying Areas 2 - 7 Business Days
International Please contact out sales department
Stocked items will be dispatched on the same day if payment is made before 13:00pm.
GW92013


Product Description

Product Features
  • Miniature circuit breaker MT60 range
  • The position of the releases on the front, with magnetic turns and opposing arc chute chambers, allows a notable reduction in arc time and short-circuit strain on the mechanism
  • It has therefore been possible to halve the system and lighten the mechanism, which has short pre-arc times thanks to the reduced energy
  • The new mechanism has been sized and optimised by means of a sophisticated planning, engineering and testing programme
  • Manual control lever with a position coherent with the contacts, allowing the circuit breaker to be used as a switch disconnector (in compliance with Standard CEI 64-8)
  • Toggle joint tripping mechanism with tripping accelerator for short-circuit condition
  • Electromagnets for instantaneous short-circuit tripping
  • Silver-graphite contacts to maintain electrical characteristics over time
  • Magnetic turns in the arc chute chambers
  • Arc chute chambers with 12 reeds in a ferromagnetic material
  • Shell-type terminals with anti-loosening tightening system

Technical Specifications
Colour: White
Material: Plastic
Handle Colour: Blue
Poles: 1
Current: 63A
kA Rating: 10kA
Voltage: 230V
Height: 85mm
Width: 18mm
Depth: 44mm
