Sonoff NSPanel Pro 120 Smart Home Control Panel - Dark Grey
SKU: SNFNSPANPUSB01NEW
Recommended and/or Required Products
Product Information
The NSPanel Pro 120 is a dark grey 4.7-inch smart-home control panel that brings device control, Zigbee coordination, Matter control, camera viewing and home-security functions onto one wall-mounted touchscreen. Unlike a conventional smart switch, it is designed as a central control interface rather than a direct high-current relay.
Product Features
- 4.7-inch capacitive touchscreen with 750 x 1334 resolution.
- Built-in Zigbee 3.0 coordinator for compatible Zigbee devices.
- Matter controller support for compatible Matter devices and ecosystems.
- 2.4GHz WiFi and Bluetooth connectivity.
- Supports live viewing of compatible cameras on the panel.
- Built-in speaker and dual digital microphones support intercom and audio functions.
- Ambient light sensor supports automatic screen-brightness adjustment.
- Quad-core ARM Cortex-A35 processor with Mali-G31 GPU.
- 2GB RAM and 8GB eMMC storage.
- Designed as a smart-home control panel; it does not contain a direct mains load-switching relay.
- 1 Year Manufacturer Warranty
Suggested / Optional Accessories
- NSPanel Pro 120 desk stand
- SONOFF R5 scene controller
- SONOFF iHost smart home hub
Application
- Central smart-home dashboard for lights, switches and scenes.
- Zigbee hub for compatible sensors and devices.
- Matter controller for compatible smart-home products.
- Viewing compatible indoor or outdoor cameras.
- Home-security, climate-control and intercom functions.
Safety Features
- Switch off the electricity supply before installing or removing the wall-mounted panel.
- Control panel only: it has no built-in relay for direct switching.
- Use a qualified electrician for wall installation.
- Consider UPS backup if control is needed during load shedding.
Frequently Asked Questions
-
Does the NSPanel Pro 120 directly switch a 230V light circuit?
No. It is a smart-home control panel and does not include a direct mains load-switching relay. -
Can it act as a Zigbee hub?
Yes. It includes a Zigbee coordinator for compatible Zigbee devices. -
Does it support Matter?
Yes. It can act as a Matter controller for compatible Matter devices. -
Can I view security cameras on it?
Yes. Compatible cameras can be displayed on the panel. -
Is a desktop stand included?
No. A compatible desktop stand, where available, is an optional accessory rather than part of the standard wall-panel package.
Technical Specifications
| Colour: | Dark Grey |
| Material: | PC V0, CRS and tempered glass |
| Mounting Type: | Wall mount / Optional desk stand |
| Mounting Box: | 4x2 / 120-type wall box |
| Channels: | No relay - control panel only |
| Connectivity: | WiFi 2.4 GHz, Zigbee 3.0, Bluetooth, Matter |
| Wireless Protocol: | WiFi 2.4 GHz | Zigbee 3.0 | Bluetooth | Matter |
| Zigbee Role: | Coordinator / Gateway |
| Relay: | No relay - control panel only |
| Wiring: | Live and neutral mains power |
| Processor: | Quad-core ARM Cortex-A35 1.5GHz |
| Sensors: | Ambient light sensor |
| Microphone: | 2 x digital microphones |
| Speakers: | 7Ω 1W speaker |
| Display: | 4.7 inch touchscreen, 750 x 1334 |
| App: | eWeLink (iOS & Android) |
| Voice Control: | Amazon Alexa | Google Home | Siri Shortcuts |
| Hub Required: | No - built-in Zigbee 3.0 hub and Matter controller |
| Compatible Hubs: | Built-in Zigbee 3.0 hub | Matter controller |
| Compatible Platforms: | eWeLink | Amazon Alexa | Google Home | Siri Shortcuts | Home Assistant |
| GPU: | Mali-G31 |
| Storage Capacity: | 8GB eMMC |
| Chip: | Quad-core ARM Cortex-A35 1.5GHz |
| Board Power: | AC 100-240V 50/60Hz |
| Input Voltage: | 100-240V AC |
| Frequency: | 50/60Hz |
| Neutral Wire: | Required |
| Height: | 122.5mm |
| Width: | 74.5mm |
| Depth: | 39.5mm |
| Operating Temperature: | 0°C to 40°C |
| Operating Humidity: | 5% - 90% RH, non-condensing |
| Certifications: | NRCS | ICASA | CE | FCC |
