Xpelair DX Window Extractor Fan
SKU: DX 100 SProduct Information
Stylish, compact and easy to install single speed fan, suitable for a wide range of domestic applications including bathrooms, shower rooms and toilets. The DX100 has a softly curved flowline grille design which will blend into wall or ceiling decor, whilst the shallow depth of the outlet spigot ensures compact window installation. The fan is supplied complete with a universal mounting kit (wall tube, gasket x 2, outer grille) and includes an air operated backdraught shutter suitable for wall and ceiling mounting (Not for window mount) applications. The DX100s is IP55 rated and suitable for 220V-240V 50Hzmains operation. Class Insulation for operation in ambient temperatures up to 40°C and are fitted with a thermal cut out.
Product Features
- Single speed axial unit
- Operated by a remote switch
- Includes universal mounting kit
- MAX airflow (m^3/h) = 76
- MAX Airflow (I/s) = 21
Technical Specifications
| Colour: | White |
| Finish: | Matt |
| Mounting Type: | Wall, Window or Ceiling Mount |
| Shape: | Square |
| Voltage: | 240V |
| Height: | 155mm |
| Width: | 165mm |
| Depth: | 35mm |
| Ambient Temperature: | 40° |
| Insulation Class: | Class 2 |
| IP Rating: | IP55 (dust-protected + protected against water jets) |
